공칭치수 Nominal Size mm | 표준단면치수 Standard Sectional Dimension mm | 단위중량 Unit Weight Kg/m | 단면적 Sectional Area ㎠ | 단면 2차 모멘트 Moment of Inertia cm4 | 단면 2차반경 Radius of Gyration cm | 단면계수 Modulus of Section cm3 | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
H×B | t1 | t2 | r | W | A | lx | ly | ix | iy | Zx | Zy | |
100×100 | 100×100 | 6 | 8 | 10 | 17.2 | 21.90 | 383 | 134 | 4.18 | 2.47 | 76.5 | 26.7 |
125×125 | 125×125 | 6.5 | 9 | 10 | 23.8 | 30.31 | 847 | 293 | 5.29 | 3.11 | 136 | 47.0 |
150× 75 | 150×75 | 5 | 7 | 8 | 14.0 | 17.85 | 666 | 49.5 | 6.11 | 1.66 | 88.8 | 13.2 |
150×100 | 148×100 | 6 | 9 | 11 | 21.1 | 26.84 | 1,020 | 151 | 6.17 | 2.37 | 138 | 30.1 |
150×150 | 150×150 | 7 | 10 | 11 | 31.5 | 40.14 | 1,640 | 563 | 6.39 | 3.75 | 219 | 75.1 |
200×100 | 198×99 200×100 |
4.5 5.5 |
7 8 |
11 11 |
18.2 21.3 |
23.18 27.16 |
1,580 1,840 |
114 134 |
8.26 8.24 |
2.21 2.22 |
160 184 |
23.0 26.8 |
200×150 | 194×150 | 6 | 9 | 13 | 30.6 | 39.10 | 2,690 | 507 | 8.30 | 3.61 | 277 | 67.6 |
200×200 | 200×200 200×204 208×202 |
8 12 10 |
12 12 16 |
13 13 13 |
49.9 56.2 65.7 |
63.53 71.53 83.69 |
4,720 4,980 6,530 |
1,600 1,700 2,200 |
8.62 8.35 8.83 |
5.02 4.88 5.13 |
472 498 628 |
160 167 218 |
250×125 | 248×124 250×125 |
5 6 |
8 9 |
12 12 |
25.7 29.6 |
32.68 37.66 |
3,540 4,050 |
255 294 |
10.4 10.4 |
2.79 2.79 |
285 342 |
41.1 47.0 |
250×175 | 244×175 | 7 | 11 | 16 | 44.1 | 56.24 | 6,120 | 984 | 10.4 | 4.18 | 502 | 113 |
250×250 | 244×252 248×249 250×250 250×255 |
11 8 9 14 |
11 13 14 14 |
16 16 16 16 |
64.4 66.5 72.4 82.2 |
82.06 84.70 92.18 104.7 |
8,790 9,930 10,800 11,500 |
2,940 3,350 3,650 3,880 |
10.3 10.8 10.8 10.5 |
5.98 6.29 6.29 6.09 |
720 801 867 919 |
233 269 292 304 |
300×150 | 298×149 300×150 |
5.5 6.5 |
8 9 |
13 13 |
32.0 36.7 |
40.8 46.78 |
6,320 7,210 |
442 508 |
12.4 12.4 |
3.29 3.29 |
424 481 |
59.3 67.7 |
300×200 | 294×200 298×201 |
8 9 |
12 14 |
18 18 |
56.8 65.4 |
72.38 83.36 |
11,300 13,300 |
1,600 1,900 |
12.5 12.6 |
4.71 4.77 |
771 893 |
160 189 |
300×300 | 294×302 298×299 300×300 300×305 304×301 310×305 310×310 |
12 9 10 15 11 15 20 |
12 14 15 15 17 20 20 |
18 18 18 18 18 18 18 |
84.5 87.0 94.0 106 106 130 142 |
107.7 110.8 119.8 134.8 134.8 165.3 180.8 |
16,900 18,800 20,400 21,500 23,400 28,150 29,390 |
55,520 6,240 6,750 7,100 7,730 9,460 9,940 |
12.5 13.0 13.1 12.6 13.2 13.2 12.8 |
7.16 7.50 7.51 7.26 7.57 7.6 7.5 |
1,150 1,270 1,360 1,440 1,540 1,810 1,890 |
365 417 450 466 514 620 642 |
350×175 | 346×174 350×175 354×176 |
6 7 8 |
9 11 13 |
14 14 14 |
41.4 49.6 57.8 |
52.68 63.14 73.68 |
11,100 13,600 16,100 |
792 984 1,180 |
14.5 14.7 14.8 |
3.88 3.95 4.01 |
641 775 909 |
91 112 134 |
350×250 | 336×249 340×250 |
8 9 |
12 14 |
20 20 |
69.2 79.7 |
88.15 101.5 |
18,500 21,700 |
3,090 3,650 |
14.5 14.6 |
5.92 6.00 |
1,100 1,280 |
248 292 |
350×350 | 344×348 344×354 350×350 350×357 |
10 16 12 19 |
16 16 19 19 |
20 20 20 20 |
115 131 137 156 |
146.0 166.6 173.9 191.4 |
33,300 35,300 40,300 42,800 |
11,200 11,800 13,600 14,400 |
15.1 14.6 15.2 14.7 |
8.78 8.43 8.84 8.53 |
1,940 2,050 2,300 2,450 |
646 669 776 809 |
400×200 | 396×199 400×200 404×201 |
7 8 9 |
11 13 15 |
16 16 16 |
56.6 66.0 75.5 |
72.16 84.12 96.16 |
20,000 23,700 27,500 |
1,450 1,740 2,030 |
16.7 16.8 16.9 |
4.48 4.54 4.60 |
1,010 1,190 1,360 |
145 174 202 |
400×300 | 386×299 390×300 |
9 10 |
14 16 |
22 22 |
94.3 107 |
120.1 136.0 |
33,700 38,700 |
6,240 7,210 |
16.7 16.9 |
7.81 7.28 |
1,740 1,980 |
418 481 |
400×400 | 388×402 394×398 394×405 400×400 400×408 406×403 414×405 428×407 458×417 498×432 |
15 11 18 13 21 16 18 20 30 45 |
15 18 18 21 21 24 28 35 50 70 |
22 22 22 22 22 22 22 22 22 22 |
140 147 168 172 197 200 232 283 415 605 |
178.5 186.8 214.4 218.7 250.7 254.9 295.4 360.7 528.6 770.1 |
49,000 56,100 59,700 66,600 70,900 78,000 92,800 119,000 187,000 298,000 |
16,300 18,900 20,000 22,400 23,800 26,200 31,000 39,400 60,500 94,000 |
16.6 17.3 16.7 17.5 16.8 17.5 17.7 18.2 18.8 19.7 |
9.54 10.1 9.65 10.1 9.75 10.1 10.2 10.4 10.7 11.1 |
2,520 2,850 3,030 3,330 3,540 3,840 4,480 5,570 8,170 13,000 |
809 951 985 1,120 1,170 1,300 1,530 1,930 2,900 4,370 |
450×200 | 446×199 450×200 |
8 9 |
12 14 |
18 18 |
66.2 76.0 |
84.3 96.76 |
28,700 33,500 |
1,580 1,870 |
18.5 18.6 |
4.33 4.4 |
1,290 1,490 |
159 187 |
450×300 | 434×299 440×300 |
10 11 |
15 18 |
24 24 |
106 124 |
135.0 157.4 |
46,800 56,100 |
6,690 8,110 |
18.6 18.9 |
7.04 7.18 |
2,160 2,550 |
448 541 |
500×200 | 496×199 500×200 406×201 |
9 10 11 |
14 16 19 |
20 20 20 |
79.5 89.6 103 |
101.3 114.2 131.3 |
41,900 47,800 56,500 |
1,840 2,140 2,580 |
20.3 20.5 20.7 |
4.27 4.33 4.43 |
1,690 1,910 2,230 |
185 214 257 |
500×300 | 482×300 488×300 |
11 11 |
15 18 |
26 26 |
114 128 |
145.5 163.5 |
60,400 71,000 |
6,760 8,110 |
20.4 20.8 |
6.82 7.04 |
2,500 2,910 |
451 541 |
600×200 | 596×199 600×200 606×201 612×202 |
10 11 12 13 |
15 17 20 23 |
22 22 22 22 |
94.6 106 120 134 |
120.5 134.4 152.5 170.7 |
68,700 77,600 90,400 103,000 |
1,980 2,280 2,720 3,180 |
23.9 24.0 24.3 24.6 |
4.05 4.12 4.22 4.31 |
2,310 2,590 2,980 3,380 |
199 228 271 314 |
600×300 | 582×300 588×300 594×302 |
12 12 14 |
17 20 23 |
28 28 28 |
137 151 175 |
174.5 192.5 222.4 |
103,000 118,000 137,000 |
7,670 9,020 10,600 |
24.3 24.8 24.9 |
6.63 6.85 6.90 |
3,530 4,020 4,620 |
511 601 701 |
700×300 | 692×300 700×300 708×302 |
13 13 15 |
20 24 28 |
28 28 28 |
166 185 215 |
211.5 235.5 273.6 |
172,000 201,000 237,000 |
9,020 10,800 12,900 |
28.6 29.3 29.4 |
6.53 6.78 6.86 |
4,980 5,760 6,700 |
602 722 853 |
800×300 | 792×300 800×300 808×302 |
14 14 16 |
22 26 30 |
28 28 28 |
191 210 241 |
243.4 267.4 307.6 |
254,000 292,000 339,000 |
9,930 11,700 13,800 |
32.3 33.0 33.2 |
6.39 6.62 6.70 |
6,410 7,290 8,400 |
662 782 915 |
900×300 | 890×29 900×300 912×302 |
15 16 18 |
23 28 34 |
28 28 28 |
213 243 286 |
270.9 309.8 364.0 |
345,000 411,000 498,000 |
10,300 12,600 15,700 |
35.7 36.4 37.0 |
6.16 6.39 6.56 |
7,760 9,140 10,900 |
688 843 1.040 |
